Striking force 30 T
CNC: Amadan 04PC
Turret 44 stations, 18 stations A, 16 stations B, 4 stations C, 2 stations D, 2 stations E, 2 Auto-Index stations B
Sheet length 1270 mm
Sheet width 1830 mm
Ball tables
Maximum thickness Standard steel 6.35 mm
Sheet length with repositioning 1270 mm
Sheet width with repositioning 3660 mm
Max. punching diameter 114.3 mm
Speed (strokes/min) 235
Max. sheet weight 100 kg
