Punching force: 30 tonnes
Press type Servovalve-controlled hydraulic cylinder
40 mm variable hammer stroke managed by CNC
Sheet size: 1525 x 2000 mm
Format without repositioning: 1525 x 1830 mm
Format with repositioning: 1525 x 4000 mm
Maximum thickness of ball tables: 6.4 mm
Simultaneous X, Y X, Y, simultaneous: 82 m/mn
Approximate tool change time: 1.5s
Max. material thickness 6.35 mm
Max. hole diameter 41 mm
Max. material weight 100Kg
Max. hole diameter 114.3 mm
Auto-Index: 2 B stations (max. diameter 31.7 mm)
Auto-Index: 2 C stations (max. diameter 50.8 mm)
Axis positioning speed (X, Y) 82 m / min
Turret rotation speed 30 rpm
Air blower/tool lubrication system
Servomotor
Electrical power requirement 30Kva 400V +/- 10% 50Hz
Air pressure required 5.0 Kgf / cm² Air flow rate
Air flow 250 L / min
Auto-index rotation speed: 60 rpm
Accuracy between two holes: +/- 0.1 mm
- CNC control FANUC O4PC
