CINCINNATI H5-800 5 Axis Machining Centre

1/44

Item details

Name

CINCINNATI H5-800 5 Axis Machining Centre

Item number

884992

Manufacturer

CINCINNATI

Model / Type

H5-800

Videos

Video 1

Year of manufacture

Refurb 2019

Item available from

Immediately

Item condition

Location

United Kingdom (Great Britain), S60 5TZ Rotherham

Show on map
All items at this location

Costs and benefits

Dismantling & loading costs (binding): 13,000.00 €
Shipping costs: not included
Delivery terms: FCA Rotherham, loaded on truck
Payment terms: 100% payment prior to collection
tax / deposit: In the case of a cross-border supply, the amount of tax due is initially retained by the deposit shown on the invoice.

tax / deposit

In the case of a cross-border supply, the amount of tax due is initially retained by the deposit shown on the invoice.
The place of taxation is determined by the place of supply (transfer of control).
The refund of the deposit will be made as soon as the customer has submitted the export documents necessary to prove the tax-free delivery to us and these have been successfully checked.
If you commission Surplex with the transport, the deposit can usually be waived. You can request a transport quotation from your responsible logistics specialist. You will find the contact details on your invoice.

Technical details

z-motion: 1,200 mm
x-motion: 1,550 mm
y-motion: 1,215 mm
control: Siemens sinumerik 840D sl CNC Control
pallet table size: 1000dia mm
numbers of pallets: 2
taper: CAT50
toolchanger positions: 45
feed range: 1 - 21,000 mm/min
weight approx.: 30,000 kg
Approx. Onsite Dimension. (l x w x h): 7,500 x 7,000 x 3,600 mm

Item description

Machine Specifications

X Axis Travel: 1550mm

Y Axis Travel: 1215mm

Z Axis Travel: 1200mm

A Axis Rotation: 180 Degrees

B Axis Rotation (Full Contouring & Turning): 360 Degrees

Table RPM (Turning): 700 RPM

Spindle Speeds: Up to 6000 RPM

Spindle Taper: CAT 50 ANSI V-Flange

Pallet Size (Round): 100 cm Diameter

Equipped With: Siemens sinumerik 840D sl CNC Control, 45 Tools, Automatic Pallet Changer with (2) 800x1000, Pallets, 5,080 PSI High Pressure Thru-The-Spindle Coolant, Chip Conveyor MAYFRAN, (50 HP) Spindle Motor

LEV
Blum LaserControl
Micro Compact NT Non contact tool setting
Spindle Probe
Twin pallet inc changer
Several tool holders
Pallet changer light guard
Operator camera
Siemens 840D controller
Hand pendant
Coolant gun
70bar internal coolant system
