SKODA PLZEN SK 125 Carousel Lathe

SKODA PLZEN SK 125 Carousel Lathe
Name
SKODA PLZEN SK 125 Carousel Lathe
Item number
870616
Manufacturer
SKODA PLZEN
Model / Type
SK 125
Year of manufacture
1957
Item available from
immediately
Item condition
Location
Czech Republic, 301 00 Plzeň 1
Shipping costs
not included
Delivery terms
EXW Plzeň 1, ex foundation, unpackaged
Payment terms
100% payment prior to collection
tax / deposit
In the case of a cross-border supply, the amount of tax due is initially retained by the deposit shown on the invoice.
max. workpiece weight between centers
200,000 kg
weight approx.
550,000 kg
Approx. Onsite Dimension. (l x w x h)
20,000 x 12,500 x 11,750 mm
  • clamping plate diameter: 8000 mm
  • clamping plate diameter with extensions: 12500 mm
  • max. workpiece weight: 200 tons
  • clamping plate speed: 0.35 - 14 rpm
  • smallest turning diameter: 5000 mm
  • cross member without bases: 1040 mm
  • transom with 3 pairs of bases: 5090 mm
  • largest distance between the clamping plate and blase side bracket holder: 4200 mm
  • vertical movement of the cross support:
    • right: 3500 mm
    • left: 2550 mm
  • horizontal movement side carrier: 2000 mm
  • vertical movement side carrier: 4000 mm
  • area required: 20000 x 20000 x 12000 mm
